束帶含插鞘固定座 (06FTHH1-6)
‧材質：耐衝擊等級Nylon 6/6
‧防火等級：UL 94V-2 / UL 94HB
‧顏色：黑色
‧工作溫度：束帶 -40℃ ~ +105℃/ 固定座 -40℃ ~ +110℃
‧RoHS. CE認證
| FTHH1 |
|
||||||||
| 黑色 ▼ | 長度 mm(in.) ▼ | 寬度 mm(in.) ▼ | 最大束徑 mm ▼ | 最小拉力 kg(Lbs) ▼ | 固定座 DiscΦ Ø mm (in.) ▼ | 固定座 長度 (L2) mm (in.) ▼ | 固定座長度 (L3) mm (in.) ▼ | 固定座寬度 (W3) mm (in.) ▼ | 固定座高度 (H2) mm (in.) ▼ |
| FTHH1-150-I | 150 (6") | 3.5± 0.3 (0.14"±0.012") | 37 (1.45") | 40 (18) | 16 (0.63") | 11.6(0.46") | 13.2(0.52") | 5(0.2") | 6.9(0.27") |
| FTHH1-200-S | 199 (8") | 4.6±0.3(0.18"±0.012") | 54 (2.13") | 50 (22) | 16(0.63") | 11.6 (0.46") | 13.2 (0.52") | 5 (0.2") | 6.9 (0.27") |
| FTHH2 |
|
||||||||
| 黑色 ▼ | 長度 mm(in.) ▼ | 寬度 mm(in.) ▼ | 最大束徑 mm ▼ | 最小拉力 kg(Lbs) ▼ | 固定座 DiscΦ Ø mm (in.) ▼ | 固定座 長度 (L2) mm (in.) ▼ | 固定座長度 (L3) mm (in.) ▼ | 固定座寬度 (W3) mm (in.) ▼ | 固定座高度 (H2) mm (in.) ▼ |
| FTHH2-150-I | 150 (6") | 3.5± 0.3 (0.14"±0.012") | 37 (1.45") | 40 (18) | 16 (0.63") | 11.6 (0.46") | 13.8 (0.54") | 5 (0.2") | 7.5(0.295") |
| FTHH2-160-S | 157 (6.2") | 4.6±0.3 (0.18"±0.012") | 40 (1.57") | 50 (22) | 16(0.63") | 11.6 (0.46") | 13.8 (0.54") | 5 (0.2") | 7.5 (0.295") |
| FTHH2-200-S | 199 (8") | 4.6±0.3 (0.18"±0.012") | 54 (2.13") | 50 (22) | 16(0.63") | 11.6 (0.46") | 13.8 (0.54") | 5 (0.2") | 7.5 (0.295") |
| FTHH2-370-S | 371 (14.6") | 4.6±0.3 (0.18"±0.012") | 106 (4.17") | 50 (22) | 16 (0.63") | 11.6 (0.46") | 13.8 (0.54") | 5 (0.2") | 7.5 (0.295") |
| FTHH3 |
|
||||||||
| 黑色 ▼ | 長度 mm(in.) ▼ | 寬度 mm(in.) ▼ | 最大束徑 mm ▼ | 最小拉力 kg(Lbs) ▼ | 固定座 DiscΦ Ø mm (in.) ▼ | 固定座 長度 (L2) mm (in.) ▼ | 固定座長度 (L3) mm (in.) ▼ | 固定座寬度 (W3) mm (in.) ▼ | 固定座高度 (H2) mm (in.) ▼ |
| FTHH3-150-I | 150 (6") | 3.5± 0.3 (0.14"±0.012") | 37 (1.45") | 40 (18) | 16(0.63") | 11.6 (0.46") | 17.5 (0.69") | 5 (0.19") | 11.1 (0.44") |
| FTHH3-160-S | 157 (6.2") | 4.6±0.3 (0.18"±0.012") | 40 (1.57") | 50 (22) | 16 (0.63") | 11.6 (0.46") | 17.5 (0.69") | 5 (0.19") | 11.1 (0.44") |
| FTHH3-200-S | 199 (8") | 4.6±0.3 (0.18"±0.012") | 54 (2.13") | 50 (22) | 16 (0.63") | 11.6 (0.46") | 17.5 (0.69") | 5 (0.19") | 11.1 (0.44") |
| FTHH3-300-S | 371 (14.6") | 4.6±0.3 (0.18"±0.012") | 106 (4.17") | 50 (22) | 16 (0.63") | 11.6 (0.46") | 17.5 (0.69") | 5 (0.19") | 11.1 (0.44") |
| FTHH4 |
|
||||||||
| 黑色 ▼ | 長度 mm(in.) ▼ | 寬度 mm(in.) ▼ | 最大束徑 mm ▼ | 最小拉力 kg(Lbs) ▼ | 固定座 DiscΦ Ø mm (in.) ▼ | 固定座 長度 (L2) mm (in.) ▼ | 固定座長度 (L3) mm (in.) ▼ | 固定座寬度 (W3) mm (in.) ▼ | 固定座高度 (H2) mm (in.) ▼ |
| FTHH4-150-I | 150 (6") | 3.5±0.3 (0.14"±0.012") | 37 (1.45") | 40 (18) | 16 (0.63") | 11.6 (0.46") | 19 (0.75") | 5 (0.2") | 12.7 (0.5") |
| FTHH4-160-S | 157 (6.2") | 4.6±0.3 (0.18"±0.012") | 40 (1.57") | 50 (22) | 16 (0.63") | 11.6 (0.46") | 19 (0.75") | 5 (0.2") | 12.7 (0.5") |
| FTHH4-200-S | 199 (8") | 4.6±0.3 4.6±0.3 | 54 (2.13") | 50 (22) | 16 (0.63") | 11.6 (0.46") | 19 (0.75") | 5 (0.2") | 12.7 (0.5") |
| FTHH4-300-S | 302 (11.9") | 4.6±0.3 (0.18"±0.012") | 84 ( 3.3" ) | 50 (22) | 16 (0.63") | 11.6 (0.46") | 19 (0.75") | 5 (0.2") | 12.7(0.5") |
| FTHH4-370-S | 371 (14.6") | 4.6±0.3 (0.18"±0.012") | 106 (4.17") | 50 (22) | 16 (0.63") | 11.6 (0.46") | 19 (0.75") | 5 (0.2") | 12.7 (0.5") |
| FTHH5 |
|
||||||||
| 黑色 ▼ | 長度 mm(in.) ▼ | 寬度 mm(in.) ▼ | 最大束徑 mm ▼ | 最小拉力 kg(Lbs) ▼ | 固定座 DiscΦ Ø mm (in.) ▼ | 固定座 長度 (L2) mm (in.) ▼ | 固定座長度 (L3) mm (in.) ▼ | 固定座寬度 (W3) mm (in.) ▼ | 固定座高度 (H2) mm (in.) ▼ |
| FTHH5-150-I | 150 (6") | 3.5± 0.3 (0.14"±0.012") | 37 (1.45") | 40 (18) | 16 (0.63") | 12 (0.47") | 17.8 (0.7") | 9 (0.35") | 11.5 (0.45") |
| FTHH5-200-S | 199 (8") | 4.6±0.3 (0.18"±0.012") | 54 (2.13") | 50 (22) | 16 (0.63") | 12 (0.47") | 17.8 (0.7") | 9 (0.35") | 11.5 (0.45") |
| FTHH5-300-S | 302 (11.9") | 4.6±0.3 (0.18"±0.012") | 84 ( 3.3" ) | 50 (22) | 16 (0.63") | 12 (0.47") | 17.8 (0.7") | 9 (0.35") | 11.5 (0.45") |
| FTHH5-370-S | 371 (14.6") | 4.6±0.3 (0.18"±0.012") | 106 (4.17") | 50 (22) | 16 (0.63") | 12 (0.47") | 17.8 (0.7") | 9 (0.35") | 11.5 (0.45") |
| FTHH6 |
|
||||||||
| 黑色 ▼ | 長度 mm(in.) ▼ | 寬度 mm(in.) ▼ | 最大束徑 mm ▼ | 最小拉力 kg(Lbs) ▼ | 固定座 DiscΦ Ø mm (in.) ▼ | 固定座 長度 (L2) mm (in.) ▼ | 固定座長度 (L3) mm (in.) ▼ | 固定座寬度 (W3) mm (in.) ▼ | 固定座高度 (H2) mm (in.) ▼ |
| FTHH6-150-I | 150 (6") | 3.5± 0.3 (0.14"±0.012") | 37 (1.45") | 40 (18) | 18 (0.71") | 12 (0.47") | 18.6 (0.75") | 5 (0.2") | 12.1 (0.48") |
| FTHH6-160-S | 157 (6.2") | 4.6±0.3 (0.18"±0.012") | 40 (1.57") | 50 (22) | 18 (0.71") | 12 (0.47") | 18.6 (0.75") | 5 (0.2") | 12.1 (0.48") |
| FTHH6-200-S | 199 (8") | 4.6±0.3 (0.18"±0.012") | 54 (2.13") | 50 (22) | 18 (0.71") | 12 (0.47") | 18.6 (0.75") | 5 (0.2") | 12.1 (0.48") |
| FTHH6-300-S | 302 (11.9") | 4.6±0.3 (0.18"±0.012") | 84 ( 3.3" ) | 50 (22) | 18 (0.71") | 12 (0.47") | 18.6 (0.75") | 5 (0.2") | 12.1 (0.48") |
| FTHH6-300-S | 302 (11.9") | 4.6±0.3 (0.18"±0.012") | 84 ( 3.3" ) | 50 (22) | 18 (0.71") | 12 (0.47") | 18.6 (0.75") | 5 (0.2") | 12.1 (0.48") |
